High-Speed Low Pressure Die Casting Machine For Brass Casting,Brass Mould..
Product Description:
Features:
- Product Name: Low Pressure Die Casting Machine
- Max. Die Thickness: 2*120mm
- Gas Flow: 0.225m³/h
- Hydraulic Fluid Temperature: ≤55℃
- Max. Die Dimension : 600*400*240mm
- Total Power: 125KW
- Low Pressure Die Casting Process: A process used to cast metal parts using a low pressure die casting machine
Technical Parameters:
| Properties | Parameters |
| Equipment Size:L*W*H | 5200*5000*3600mm |
| Total Weight | 13T |
| Total power | 125KW |
| Voltage | 380V |
| Max. Die Dimensions | 600*400*240mm |
| Max. Die Thickness | 2*120mm |
| Max. Die Opening stroke | 370mm |
| Max.Die Weight | 200Kg |
| Max. force of die closing | 2400KG |
| Max. force of ejector | 500KW |
| Max. die ejector stroke | 48mm |
| Furnace Melting rate | 350KG/H |
| Furnace Capacity | 1800KG |
| Furnace Inductors | 3*35KW |
| Hydraulic Motor Power | 8.7KW |
| Hydraulic Rated Pressure | 8Mpa |
| Hydraulic fluid temperature | ≤52℃ |
| Cooling system Water PH value | 7~8.5 |
| Cooling system Pressure | 3-5bar |
| Cooling system Temp. | 20±2℃ |
| Cooling system Flow | ≥400L/Min ≤600L/Min |
| Air pressure Compressed air pressure | 0.5-0.6Mpa |
| Air pressure Compressed air consumption | 15m³/H |
Applications:
- Manufacturing industry: Producing a wide range of mechanical parts and assemblies for machinery.
-
- Electronics and electrical industry: Crafting well-conductive brass electrical components.
-
- Construction and decoration: Creating decorative pieces, architectural components, and items requiring a brass aesthetic.
-
- Automotive industry: Manufacturing automotive components such as engine parts, transmission elements, and more.
Packing and Shipping:
Packaging and Shipping for Low Pressure Die Casting Machine
The Low Pressure Die Casting Machine is packed and shipped with utmost care and attention to the following guidelines:
- The die casting machine is securely fastened in a wooden crate for protection during transit.
- The crate is then placed in a cardboard box for additional protection.
- The box is sealed and labeled with a warning sticker about the fragile nature of the machine.
- The box is then secured on a pallet and shrink-wrapped to ensure the box does not open during transit.
- The pallet is then loaded onto a freight truck for delivery.
```
FAQ:
Q1: What is the brand name of the Low Pressure Die Casting Machine?
A1: The brand name is DZ.
Q2: What is the model number of the Low Pressure Die Casting Machine?
A2: The model number is RD-5040-S.
Q3: Where is the Low Pressure Die Casting Machine made?
A3: The Low Pressure Die Casting Machine is made in China.
Q4: Does the Low Pressure Die Casting Machine have any certifications?
A4: Yes, the Low Pressure Die Casting Machine has CE and ISO certifications.
Q5: What advantages does the Low Pressure Die Casting Machine have?
A5: The Low Pressure Die Casting Machine has accurate temperature control, easy and safe operation, high efficiency, and stable performance.
